Product Description

[Summary]
- It is a point of switch 10 stations and 5 stations of the desktop.

[Features]
- For independent power supply with the (AC100V adapter) does not depend on the type of power pack.
- The pulse-driven due to the capacitor charge and discharge type.
- There is TOMIX for KATO and for the shape of the connector.
- It is a slanted design, easy to operate.
- The metal case High quality.

- Name: desktop 10 stations switch point
- Model: CP-1610K
- Connectors: KATO
- Power: AC 100V 50/60Hz adapter type
- Power indicator: green LED lights up when energized
- Point connection: 1 per switch, single point until two, complex point one
- (Mm) Dimensions: W60 × H61 × L220 (projection part is excluded)
- Weight (g): about 420
- Accessories: AC adapter, seal point number display

[More]
- CP-16T 2 branch code connector (TOMIX use)
- The 2-point linkage, such as siding with TOMIX rail, please use the code two branch connector (sold separately).
- In the case of rail KATO, please use the (24-827) branch connector



Item Size/Weight : 29.3 x 11.8 x 6.3 cm / 682g

Product Specifications

Item series

Control Systems

Item code

CP-1610K

JAN code

4582330652396
