- Green Max Economy Kit Series (Unpainted Board Kit)
- Dolly, pantograph, power unit sold separately
[Commentary]
- In 1972 (Showa 47), 113 series squirrels of the side windows from the 1000 series ATC car, side sidetrack indicator installation, minor change to the car body with air conditioner, 113 series ground type, 115 type (From 300 series onwards Classification), ACC 415 series etc. are also being increased with this type of body. Among them, the 113 series 700 series for Kosan Line was introduced, and it appeared as the 113 series of the 115 series car body of the 115 series. In addition, the 62 series which modified the 73 series for the Minobu line carried almost the same car body while non cooling.
- This kit is a window glass, light lenses are all fit-in type as with the initial type, using the attached front side, side plate parts 113 series 1000 (with ATC), 113 · 115 type mass production type air conditioner etc. Each type Can be produced.
[Specification change information (difference from old product)]
- Specification change version will be revised product contents.
- The sticker that came with the previous product is not included.
[Optional item]
- Truck: No. 5509 DT 21, No. 5029 TR 62
- Power unit: No. 5509 DT 21
- Coreless motor power unit: No. 5711 20 m class A
* Installation requires processing.
* This set does not include the underfloor equipment / bogie frame corresponding to the power unit or coreless motor power unit.
- Power bogie frame · Underfloor equipment set: No. 8484 A - 03 (DT 21 + 4643 BM)
- Pantograph: No. 5801 PS 16 N or No. 5 807 PT 71 A (Approximate / small machining is required)
- Extension set: No.414-1 Intermediate intermediate car 2 sets for extension
- Vehicle mark: No. 6308, 6309, 6315
[Color guide]
- Body (Shonan color): GM railroad color (3) Yellow baby color (13) Green No. 2
- Body (Ska color): GM Railway color (5) Cream color No.1 · (7) Blue 15
- Body (Yahiko Line old color): GM Railway Color (12) Yellow No. 5 · (21) Ivory A (formerly Odakyu Ivory) · (27) Red A (formerly Seibu Red)
- Body (Hanwa Line Rapid): GM Railway Color (6) Blue No. 22 · (14) Gray No. 9
- Body (Kansai Line Rapid): GM Train Color (31) Vermill No. 4 [Substitution] · (14) Gray No. 9
- Rooftop Equipment: GM Railway Color (9) Mouse No. 1
- Roof: GM train color (9) Mouse color 1, or (35) Dark gray
- Underfloor equipment: GM Railway color (10) Black
- Surface Protection: GM Railway Color (40) Clear Coat (Gloss), or (44) Clear Coat (Semi Gloss)
* Please refer to the assembly instructions in the set for the body color other than the above.
[Drill Blade Guide]
- φ 0.8 mm
- φ1.2 mm
- φ1.3 mm
- For assembly, please use plastic model or rubber type adhesive.
※ This product does not include stickers.
- JR East commercialization licensed
- JR Tokai approved
- JR West commercialization licensed
( This is a machine translation. Please allow for possible misinterpretations in the text. )
