Product Description
- With 5 drawings correctly created based on 3D measurement data
- Various hands were added after the war, and equipment and materials etc were still lost, Kawasaki Aircraft Manufacturing 3-war battle [Hayan] Type II reformer No. 17 (March 24, 2018 Kagamigara aerospace from March 24 The work aimed at restoring and restoring to the figure of the time at the science museum was done in 2015-2016 by volunteers mainly by engineers of Kawasaki Heavy Industries.
- The circumstances of the time, the reason of the change, the basis of the specification, the concrete repair process, additionally restored, which was obtained by comparing features of Hayan I type, II type reform, Five type fighting side in the repair process side by side Details of the equipment, furthermore, unknown to date, to disclose about wasteful information and knowledge etc to be buried as it is.
- Filled with maniac information thoroughly delved into the things that people in charge of various occupations such as drawing, material, inspection, electricity, structure, software, project, flight engineer, aerodynamic etc are interesting,
[Vehicle collection lovers] It is also a sticky book that Kawasaki's commitment to.
- Includes aircraft main wing exterior and interior (cockpit), excluding movers H 140 and radiators as 2 volumes [Aircraft version].
- Chapter 1: Purpose of this magazine, gallery of repair aircraft, folding drawing
- Chapter 2: Outline of Project 17, Outline of Project, Carrying Out from Knowledge, Painting / Putty Peeling, 3D Measurement, Formulation of Outer Shape
- Chapter 3: Restoration and Restoration Visa: upper and lower part of motor cover, wing drum fairing, instrument panel, switchboard, windshield, radio equipment · air fighting, Pitot tube, bulletproof board, head rest etc.
- Chapter 4: Kobe Memorial Exhibition, Kokuragahara Museum Introduction
- Chapter 5: New discoveries: Joint of cutting main wing, periphery of cockpit, control stick and machine gun launcher, sighting fixture fittings, control system, fuselage, main wing machine gun area and more
- Chapter 6: Actual coverage Interpretation of the British Five-type battlefield, three Australian warfare materials etc.
- 148 pages
( This is a machine translation. Please allow for possible misinterpretations in the text. )
This item is written in Japanese
See Kawasaki Ki61 Hien (Tony) List
Item Size/Weight : 29.7 x 21 x 0.7 cm / 562g
Product Specifications
- Item code
- 200484
- ISBN code
- 4910123200484
Purchase Information
This item is limited to 4 per household.
